Sunday, 9 June 2024

Warg Riders - Removable Riders and with arrows.

Recently got into this old game again, I say old as I played it when it first came out in 2001 but I wasn't overwhelmed at the time even though I'd read all the books in the 1970 and many times since and even The Silmarillion twice.

Either the rules or I have changed sufficiently for me to pick it up and play and I've gone down the inevitable route of buying units to make a fighting force with a little extra so I can tweak for variety.

Having played a few games with friends and using proxy pieces, as well as original unpainted plastics I'd bought in 2001. (Is it really 23 years ago!😰) I decided I needed to assemble some forces, Minas Tirith and Mordor were obvious starters as I had the original ancient plastics.
I then purchased the Mordor  Battlehost box and started to assemble the wargs as a newbie player I'd managed a few game with proxy pieces before assembling my wargs. and learnt that either the rider or mount could continue alone and this is reflected in my assembly.

I assembled the Wargs enlarging the hole to glue in a small magnet and painted them up.

Wargs undercoated and prepped with magnets

Painting position
Then I painted the riders with their feet still on the sprue using Blu-Tack to attach them to my dowel stand.

When I'd finished I removed the sprue and tag that slots into the Warg, drilled a hole at that point glued in the top of a panel pin and voila, separateable riders and mounts, no need to buy spare Wargs.


Drilled a hole with a small 0.6mm bit using it to locate the position as I find I have more control and it gives the larger bit something to fix on. Also if it's not quite right you can alter the point of entry with the larger bit.

The panel pins I used have a 1mm shaft, a 2mm head slightly bevelled at the top. Using a 1mm bit I drilled into the prepared position and when that was deep enough a short way with the 2mm bit. As nothing is ever exact I used a 3mm bit to help counter sink the panel pin's head. I did this just using the bit with my fingers, a single turn is enough. Why not fix it in the drill? I feel it gave me more control, slowed me down and stopped it going too deep.

Ready for the panel pin.

Why a panel pin + magnet rather than 2 magnets? Well the pin will fit anywhere on the magnet, so you can choose the position of the model. A magnet would over-ride your choice and place it where it wants it. Oh and get the magnets the wrong way around and the opposite poles will reject any idea of placing them together.



Tools for the job

I also have a thing about Arrows, some models call out for them.

I used the small drill bit 0.6mm as my pins are 0.5mm wide I drill into the hand to create a hole for the arrow/pin.

I then push the sharp end into the hand, align it with the bow and cut off at the required length. This leaves you with a nice sharp arrow.

Remove the pin push the sharp end into BluTack paint twice.

Apply glue to blunt end use that to dab glue on bow above fist then push blunt end into hole you drilled and push home with a block of wood, against the sharp end of the wood. I don't recommend pushing in with your fingers.

When secure paint the end of the pin with bolt gun or whatever your metal choice is.


If you look closely you might notice I have four types of Warg positions. In the box you only get two variants 'A' and 'B' did you know you could glue Left 'A' to right 'B' and Left 'B' to right 'A' swopping the sides?

Monday, 20 May 2024

Long Spears, Lances and Flagpoles

In the smaller scales I play I often want to replace the long spear, lance or flagpole. At that scale the metal can be too thin and can easily bend and eventually break when bent once to often.




Flag Staffs replaced


I recently bought some Dark age Arabs from Pendraken and wanted to have a standard bearer in the heavy cavalry. I also wanted my own flag rather than the supplied one for the foot.

Not because there was anything wrong with it, I just wanted a bigger banner and will use both in my units as shown. I'd imagined small regimental flags and large National/Army Flags rippling in the wind above them.


Heavy Cavalry with spears replaced with Flag Staffs

Flagstaff created by replacing the spear


So I carefully cut away the provided flag, try to brace the pole so it won't bend or indeed break. Cut away and file down. As you can see I don't always win but have a back up plan.

Pendraken sell the perfect wire. Just remember to use a larger bit in this case I used a 0.8mm drill bit. I find the 0.1mm difference is essential as you'll never push the rod through




The rod can be cut to length and has a degree of flexibility, enough to bend it if you're not careful..

I then user a Superglue 'gel' on the end of the rod, push it through to rest the base of the spear/pole on the ground or foot of rider. If done swiftly it will pass through and leave glue in the fist.
On occasion the fist breaks looking like pincers instead of a hole through the fist, in that case I just rest the rod, glue and paint as if being held.

Pro tip, get quality bits and replace as soon as you feel it's becoming a struggle.

I also did this with my Polish Hussars the lance in Pendraken's P1 model and they sell the 2 winged Hussar with no lance just a fist, you can tuck the lance behind the fist or try like I did to drill through the fist and more times than not it work, as you can see the hand was damaged in this example, but it won't mater when painted. Option a was a shorter length, but I think with Winged Hussars size does matter.


In the image below the Winged Hussars lance is 30mm long and rests on the boot. I defy any white metal lance to remain as straight and true as these.
